PASSIVE PURPLE® Fire rated Intelligent Airtight Vapour Control for Energy-Efficient Building Solutions - Spray-applied Liquid Airtight Membrane

Name: PASSIVE PURPLE® Fire rated Intelligent Airtight Vapour Control for Energy-Efficient Building Solutions - Spray-applied Liquid Airtight Membrane
Brand: Intelligent Membranes
SKU: jRWzETbNCzg37SjYvJuq2B

Verified by manufacturer 3 days ago

Intelligent Membranes

Product certifications:

QA Certificate
Certificate type
Certificate of Compliance
Certificate type
EPD
Certificate type

The world's first Passivhaus certified liquid airtight, vapour control and smoke tight membrane. BBA approved, fire rated, spray or roller applied, sealing up to 300m2 a day on any substrate.

Jump to:

BOS

+44 (0)1223 208174 Website

Application

Passive Purple is applied with an airless spray machine, such as the Graco 495, Graco 595 or similar products. Passive Purple airtight liquid adheres to most substrates known to the construction industry. From Blockwork, Concrete, OSB, MgO Board, Spray applied & PIR insulation, Timber and Steel. A build with multiple substrate changes is an easy task to perform unlike traditional methods.
Floor/ wall connections.
Wall/ ceiling connections.
Entire walls.
Wall/ wall connections.
Vertical and horizontal joints.

Description

Passive Purple is the world's first Passivhaus certified liquid applied airtight, vapour control and smoke tight membrane, trusted by architects, contractors and self builders to hit the toughest airtightness targets first time.

Spray or roller applied to the warm side of the insulation, it forms a seamless, flexible purple membrane that seals walls, floors, roofs and junctions in one pass. One installer can cover up to 300m2 per day, slashing programme time compared with tapes and foil VCLs. Certified by the Passivhaus Institut and BBA approved (Certificate 22/6002), it is fire rated, low VOC and also certified as a radon and methane gas barrier.

Passive Purple bonds to virtually every substrate: brick, block, concrete, timber, OSB, plasterboard and steel, on new builds, retrofits and light gauge steel frame. Once cured it can be plastered, rendered or painted, giving a permanent airtight layer for the life of the building.

Pair it with Passive Purple Brush for junctions, penetrations and cracks up to 5mm, IM Fleece Tape for window and door reveals, and FRED where a Class B fire rated build up is specified.

Product page: https://intelligentmembranes.com/products/passive-purple-internal-airtight-vapour-control-paint-11-4kg

Internal airtightness solutions: https://intelligentmembranes.com/pages/internal

Application and coverage rates: https://intelligentmembranes.com/pages/intelligent-membranes-application-coverage-rates

Blog, the science behind airtight buildings: https://intelligentmembranes.com/blogs/home_blog/the-science-behind-airtight-buildings

Watch Passive Purple in action: https://www.youtube.com/watch?v=L17mIh2OdbI

General information

Color	Purple Green Blue Red Orange Other White Show more
Finish	Other
Material	Polymer
Shape	Formless
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	Lifetime

Uniclass	Pr_25_57_65_60 Plastics sheetsPrimary
CAWS	J41/395 Air and vapour control layer J42/395 Air and vapour control layer J21/395 Air and vapour control layer J31/330 Air and vapour control layer H30/261 Air and vapour control membrane H31/261 Air and vapour control membrane H11/785 Air and vapour control layer P10/60 Air and vapour control layer P10/310 Air and vapour control layer H30/30 Air and vapour control membrane

SKU Code	IM/00PPB11/4

Product range	Methane and Radon Barrier Vapour Control - Air barrier / Internal

Specification data - Plastics sheets

Classification data
Product reference	PASSIVE PURPLE® Fire rated Intelligent Airtight Vapour Control for Energy-Efficient Building Solutions.
Material	Polymer.
Purpose	Airtight vapour control membrane.
Standard	To BS EN 12114, BS EN ISO 12572, BS EN ISO 15105 and BS EN ISO 4624.
Third-party certification	British Board of Agrément (BBA), EOTA TR008 and PASSIVHAUS certified.
Performance characteristics	-
Tensile strength (minimum)	42 N/50 mm². Flatwise tensile strength to ASTM C0297-16, all substrates met ICC-ES AC212 criteria for acceptance.
Tear resistance	To EOTA TR008, Pass. Manufacturer guidance Resistance to fatigue movement.
Elongation to break	350.5% and 325.2%. Guidance for specification option: Average and average after ageing respectively.
Resistant to underground gases	Radon diffusion coefficient (to K124/02/95): 3.3 x 10^-12. Methane permeability to ISO 15105, 62–75 cm³·mm/m²·day·atm. Guidance for specification option: See Passive Purple Radon Certificate (linked) for further details.
Water vapour resistance (minimum)	µ-value to ISO 12572, 76584. SD-value to ISO 12572, 22.9 (at 0.3 mm dry thickness) and 34.4 (at 0.45 mm dry thickness). G-value: 4–200 MN·s/g.
Fire performance	Class C-S1, d0.
UV stabilization	- Manufacturer guidance Consult manufacturer for more details and insert requirements.
Anti-static properties	- Manufacturer guidance Manufacturer's standard.
Environmental performance requirements	-
Environmental rating	Passivhaus certified score of 0.03 ACH. Class M1.
Volatile organic compounds (VOC) emissions level (maximum)	To EN ISO 16000-9/ 6, EN 717-1 and EN 180 16000-28, free from VOC.
Recycled content As defined in clause 7.8 of BS EN ISO 14021	0%. Guidance for specification option: Grinded as solid film in plastics.
Form	Liquid.
Root inhibitor	- Manufacturer guidance Consult manufacturer for more details and insert requirements.
Physical properties	-
Colour	Purple. White. Blue. Green. Orange. Red. Other. Guidance for specification option: Passive Purple and Passive Purple Editions can be made into other colours on demand. Consult manufacturer for more details and insert requirements.
Weight (minimum)	1.2 kg/L. Guidance for specification option: Density.
Drying time	24–72 hours. Guidance for specification option: Depending on conditions.
Air tightness	0.05 m³/hour·m. Guidance for specification option: Airtightness floor/ wall after ageing (to NBN EN 12114 Eurocode 7). (50 BAR) (V).
Adhesion	Adhesion of universal bonding compound on Passive Purple Internal Liquid: BS EN 14496, Pass. Adhesion on red brick (dry or moist): to ISO 4624, >1 N/mm². Adhesion on concrete brick (dry or moist): to ISO 4624, >1 N/mm². Adhesion on ethylene propylene diene monomer (EPDM): to ISO 4624, adhesion value exceeding substrate strength. Adhesion on roofing: to ISO 4624, 1 N/mm². Adhesion of spray plaster on Passive Purple Interal Liquid: to ISO 4624, 1 N/mm². Adhesion on insulation Kingspan KoolTherm K5 polyurethane (PUR), Polystyrene (EPS) Polyisocyanurate (PIR): adhesion value exceeding substrate strength.
Water penetration	To ASTM E331, all substrate meet ICC-ES AC212 criteria for acceptance. Manufacturer guidance Water spray/ rain penetration.
Watertightness	To EN 14891, Pass.
Temperature resistance	-40°C to +70°C. Guidance for specification option: After drying.
Dangerous substances	To EN ISO 16000-9/ 6, EN 717-1 and EN 180 16000-28, free from carcinogenics, ammonia and formaldehyde.

Sustainability data

Contains Red List materials	No
Country of material origin	Europe
Country of product manufacture	Europe
Manufacturing plant location	Belgium
Material	Polymer
Carbon dioxide equivalent
Carbon dioxide equivalent, as defined in BS EN 15804 Certified
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/unit) Stage:A1–A3 ('Production stage') Normalised unit : 0.275 (kg CO₂ eq/kg) Declared unit : 0.33 Lower emissions
Recyclability	Not recyclable due to its adhesion to other products
Recycled content As defined in clause 7.8 of BS EN ISO 14021	0 % Guidance for specification option: Grinded as solid film in plastics.
Expected Life	Lifetime
