GH3+ Ceiling Hoist

Name: GH3+ Ceiling Hoist
Brand: Guldmann Limited
SKU: hdrobzjDgD86DmhhAzNFcU

Verified by manufacturer 7 days ago

200 k.g.

Guldmann Limited

Ceiling-mounted assisted transfer hoist.

Jump to:

BOS

+44 (0)1347 825287 Website

Application

The GH3+ is a professional ceiling hoist designed for hospitals, care homes, rehabilitation centres, SEN schools, hydrotherapy pools and private care environments. It is a high‑capacity (200–400 kg) lifting module suitable for both general and bariatric care.

Description

A professional ceiling‑mounted patient hoist designed for safe and efficient assisted transfers in hospitals, care homes, rehabilitation centres, SEN schools and bariatric environments. The GH3+ provides 200–400 kg lifting capacity, smooth and quiet operation, and in‑rail charging for continuous availability. Its modular rail system supports single‑room and multi‑room layouts, with optional motorised horizontal movement for enhanced handling.

The GH3+ integrates with MyGuldmann to:

Log activations and usage times.
Automatically upload data, daily updates, and fleet‑wide monitoring.
Integrated weighing with data capture.
Tracks service intervals and alerts when maintenance is due.
Manage all equipment, data, and service information in one place.
Maximise the value of ceiling lifts and equipment investments.
Easily add new features or lease additional functionalities as needs evolve.

General information

Color	White
Finish	Other
Material	Plastic
Shape	Other
Length	345 mm
Width	205 mm
Height	2500 mm
Warranty description	One year

Uniclass	Pr_65_80_47_12 Ceiling track hoistsPrimary
CAWS	N13/490 Hoist systems

Specification data - Ceiling track hoists

Classification data
Standard	To BS EN ISO 10535.
Form	Ceiling-mounted track hoist.
Supports	-
Finish and colour	White.
Safe working load (maximum)	400 k.g.
Electrical supply	-
Voltage rating	100–240 V AC.
Operation	Wired hand control. Infra-red (IR) remote control.
Sound	52 dB (A). Manufacturer guidance Sound level.
Cover	Impact resistant UL 94 V-0 flame retardant recyclable plastic.
Speed	60 mm/s. Guidance for specification option: (85 or 150 k.g. load.) 55 mm/s. Guidance for specification option: (Maximum capacity load.) Manufacturer guidance Lifting speed. 60 or 100 mm/ second for maximum 5 kg load.
Ingress protection	IP20. Guidance for specification option: Lifting module, remote control and transformer. IP44. Guidance for specification option: Hand control. Manufacturer guidance Protection classification (IP) in accordance with IEC 60529.
Weight	9.6 kg. Guidance for specification option: Own weight. 10.5 kg. Guidance for specification option: With scale module and horizontal motor. 11.1 kg. Guidance for specification option: With horizontal motor.
Battery capacity	24 V NiMH, 2.0 Ah.
Battery recharge time	Two hours. Manufacturer guidance Maximum.
Power supply	33 V AC, 2.5 A.
Lifting capacity	21/1000 mm. Manufacturer guidance Maximum number of lifts in series.
Operating time	On: Four minutes; Off: 16 minutes. On: Two minutes; Off: 18 minutes. Manufacturer guidance Lift intermittent.
Protection	Guidance for specification option: At battery voltage below 22 V the indicator light turns yellow. The hoist stops if the voltage drops below 20 V. Manufacturer guidance Battery protection.
Motor	Guidance for specification option: Built-in motor with infra-red remote control, GH3 Sealing kit, Guldmann Class III Scale Module 2, Guldmann CLM Online, SMART Module 3.Guldmann Trainer Module 1. Manufacturer guidance For horizontal movement along the traverse rail. In environments in which high hygiene standard are required around the ceiling hoist, e.g. in an operating theatre, a sealing kit is offered for the GH3, which protects against external dirt and particles. The GH3 Sealing kit consists of three silicone covers to seal the openings on the top of the ceiling hoist where the trolley is attached, as well as two large O-rings for sealing the groove along with the side cover of the GH3 hoist.

Sustainability data

Contains Red List materials	No
Country of material origin	Denmark
Country of product manufacture	Denmark
Material	Plastic
Recyclability	Recyclable plastic
Expected Life	15 year
