GenieMat RST - Sound Control Underlayment

Name: GenieMat RST - Sound Control Underlayment
Brand: Pliteq
SKU: kBrr7L4nFXFRmE7CgMEFxZ

Verified by manufacturer 1 month ago

GenieMat® RST03

Pliteq

Product certifications:

Indoor Air Comfort – Eurofins
Certificate type
EPD
Certificate type

Acoustic underlayment / underlay for floors.

Jump to:

+44 203 9846444 Website

Application

Suitable for use in multi-family housing, high-rise residential, or commercial buildings and protects ceramic tile, porcelain, and stone from substrate cracks.

Description

GenieMat RST is an acoustic underlayment for floors. It is made from 94% recycled rubber content and can be used directly under tile, vinyl plank/ tiles and wood flooring. In fact the acoustic underlay can be used under any hard surface floor finish in concrete and steel, wood frame construction.

The acoustic underlay is used when superior sound control is required in residential housing, high-rise residential, or commercial buildings and protects ceramic tile, porcelain, and stone from substrate cracks. GenieMat RST acoustic underlayment engineered for direct adhered floor coverings such as tile, stone, wood, and vinyl floor coverings.

Features and benefits:

Tested by third party accredited laboratories to significantly reduce impact sound.
Exceeds Part E by up to 12 dB.
Mould, bacteria, fungi, and water resistant.
Qualifies for LEED® points.
Third-party verified EPDs available.
Can be installed directly under hard surface or resilient floor coverings.
Suitable for high point loads.
CE marked.
Meets requirements for VOC emissions (IAQ test, ASTM D5116/ISO 16000-9).
Exceeds pass criteria for point load test for crack isolation membrane (ANSI 118.12).
Complete floor covering system warranty available.

General information

Color	Black
Material	Rubber
Shape	Rectangle
Length	3050 mm 3800 mm 4600 mm 9100 mm 15200 mm 22900 mm Show more
Width	1220 mm 760 mm
Height	3 mm 5 mm 10 mm 12 mm 15 mm
Warranty description	Lifetime Guidance for specification option: Pliteq Inc. is a corporation duly organized and validly existing under the laws of the province of Ontario. Pliteq offers a limited lifetime warranty on the GenieMat® brands of Impact Sound Insulation products against defects in material and workmanship and GenieMat® shall meet all published specifications and shall perform effectively. Pliteq warranties that during the warranty period GenieMat® shall not harden, become brittle, chip, crack, tear, or exhibit any signs of excessive deterioration except for normal wear and tear. All other warranties, including implied warranties for a particular purpose, are expressly excluded. The sole remedy against the seller will be the replacement or repair of the defective goods, or at seller's option, credit may be issued not exceeding the selling price of the defective good. Manufacturer guidance The recommendations for applications and installation are based on our extensive experience and on current technological practice. Our liability and responsibility in the event of damages is limited to the extent defined in our General Terms and Conditions of Business and is not in any way increased by the above recommendations or by advice given by our sales representatives or applications engineering staff.

Uniclass	Pr_35_57_11_74 Rubber crumb underlaysPrimary
CAWS	M50/120 Interlocking resilient floor tiling M50/110 Resilient floor tiling M50/15 Carpet tiling M50/25 Carpeting M50/150 Sheeting M42/270 Plywood underlay M50/170 Carpeting M50/130 Carpet tiling M50/155 PVC sheet flooring in special wet areas M50/20 Sheeting M51/371 Plywood underlay M51/370 Hardboard underlay K11/755 Hardboard underlay K11/715 Plywood underlay M50/10 Resilient floor tiling

Specification data - Rubber crumb underlays

Classification data
Product reference	GenieMat RST.
Thickness (minimum)	3 mm.
Recycled content As defined in clause 7.8 of BS EN ISO 14021	94%.
Roll length	15.24 m.
Roll width	1.22 m.
Roll weight	54.4 kg.
Impact sound reduction	Impact insulation class (IIC) 56 (Ln,w 54) and ∆IIC 23 dB (∆Lw 19 dB). Guidance for specification option: GenieMat RST03 tested over 200 mm concrete slab with wood laminate floor covering, no ceiling. Manufacturer guidance Reduction of Impact Sound Pressure Level: (ISO 10140).
Frequency	≤92 Hz @ 19.2 kN/m² (400 psf) loading.
Thermal resistance	0.023 m²·K/W.
ThermalTransmittance	44.33 W/m²·K.
Low temperature stability	-40°C.
Upper temperature stability	+115°C.
Deflection	<2% up to 48 kPa.
Dynamic stiffness	1879 NM/m³ (dynamic); 266 MN/m³ (static). Guidance for specification option: Dynamic-static stiffness ratio: 7.07.
VOC emissions	FloorScore® certified.

Sustainability data

Contains Red List materials	No
Country of product manufacture	Canada
Material	Rubber
Carbon dioxide equivalent
Carbon dioxide equivalent, as defined in BS EN 15804 Certified
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/m²) Stage:A1–A3 ('Production stage') Normalised unit : Declared unit : 1.14 Lower emissions Value guidance: A1-A3 GenieMat RST02 - 0.91 kg CO₂ eq/m². GenieMat RST03 - 1.14 kg CO₂ eq/m². GenieMat RST05 - 2.27 kg CO₂ eq/m². GenieMat RST10 - 4.91 kg CO₂ eq/m². GenieMat RST12 - 5.73 kg CO₂ eq/m². GenieMat RST15 - 6.81 kg CO₂ eq/m².
Recyclability	100% Recyclable
Recycled content As defined in clause 7.8 of BS EN ISO 14021	94 %
Expected Life	Lifetime
