Tiny Stuff Nursery Toilet Cubicle

Name: Tiny Stuff Nursery Toilet Cubicle
Brand: Bushboard Washroom Systems Ltd
SKU: vWTG4rw68efjXQg9sfuFw4

Verified by manufacturer 5 months ago

Designed specifically for nursery and early years children; Tiny Stuff is a safe, fun and reliable washroom panel cubicle.

Jump to:

+44 (0)1536 533620 Website

Application

Designed specifically for Early Years and Nursery school children.

Description

Low height toilet cubicle designed with easy supervision in mind specifically for Early Years and nursery school children.

Features and benefits:

Department for Education compliant.
Anti-finger trap hinges as standard.
Faceplate 'vacant' and 'occupied' indicators
Emergency key release lock body.
Available in DfE compliant height suitable for Early Years children.
Low height doors and no headrail for easy supervision.
Sturdy floor and wall channels to ensure stability.

Components:

SGL: Solid grade laminate panels, supplied with polished black radiused edges. DfE compliant material option.
Frame comprising: Pilaster, legs, hinges and channel.

General information

Color	Other Manufacturer guidance Panels: 34 laminate options; select from manufacturer literature.
Finish	Laminated Guidance for specification option: Panels. Smooth Powder-coated Guidance for specification option: Aluminium components.
Material	Laminate Guidance for specification option: Panels. Aluminium Guidance for specification option: Frame components.
Shape	Rectangle
Length	Bespoke
Width	Bespoke
Height	1350 mm Guidance for specification option: To top of door including floor clearance. DfE compliant for Early Years.

Uniclass	Ss_25_12_60_60 Panel cubicle systemsPrimary
CAWS	K32/10 Panel cubicles K32/120 Panel cubicles

Product range	Cubicles

Specification data - Panel cubicle systems

Classification data
Panels	SGL panel, 1400 kg/m³, polished black, radius edges.
Panel supports	Aluminium frame.
Pilasters	SGL.
Doors	SGL panel, 1400 kg/m³, polished black, radius edges.
Hardware	Pilaster, legs, anti-finger trap hinges and channel.
System accessories	Not required. Toilet roll holders. Coat hooks. Door handles. Manufacturer guidance Selection available, consult manufacturer literature.
Overall thickness	13 mm (nominal).
Floor Clearance	100 mm.
Partitions	Straight cut to door height.
Height:	Pilaster: 1350 mm.
Hinge & Channels colour	Light grey. Guidance for specification option: Powder-coated aluminium. Manufacturer guidance Frame.
Legs & Headrail colour	Light grey. Guidance for specification option: Powder-coated aluminium. Manufacturer guidance Frame.
Pilaster Foot colour	Light grey. Manufacturer guidance Frame.
Height	1350 mm. Guidance for specification option: Including 100 mm floor clearance. DfE compliant for Early Years. Manufacturer guidance Doors.
Colour	- Manufacturer guidance Panels: 34 laminate options, select from manufacturer literature.
Lock	Satin anodized aluminium slider lock body with emergency release key function. Manufacturer guidance Door.
Shape (see manufacturer's guidance)	Angled Door. Curvy Door. Manufacturer guidance Door shape: If the angled door shape is selected, the arrowhead pilaster must be used; if the curvy door is selected, the crescent pilaster must be used.
Shape (see manufacturer's guidance)	Arrowhead. Guidance for specification option: Angled door shape must be used. Crescent. Guidance for specification option: Curved door shape must be used. Manufacturer guidance Pilaster.
Colour	- Manufacturer guidance Pilaster: Refer to manufacturer standard colour range.
