Rockfon Sonar® - placeholder

Name: Rockfon Sonar® - placeholder
Brand: Rockfon
SKU: cDtmHqynkbQh89BHHkr3kq

Verified by manufacturer 1 month ago

Rockfon

Stone wool tile with micro-textured white painted fleece surface, offering high sound absorption and fire safety.

Jump to:

+44 (0)208 2227457 Website

Application

Office, Healthcare, Education, Leisure, Retail

Description

Rockfon Sonar® is a stone wool tile with a visible side featuring a micro-textured white painted fleece and a rear side with back fleece. It has durable painted edges.
Features and benefits:

Aesthetic white, micro-textured surface suitable for most applications
Highest sound absorption/Class A sound absorption and highest fire safety (Class A1)
Full range of formats and edges for complete design freedom
Easy to clean with a vacuum and damp cloth

General information

Color	White
Finish	Micro-textured
Material	Stone wool
Shape	Square Rectangle
Length	600 mm 1200 mm 1800 mm
Width	600 mm
Height	20 mm

Uniclass	Pr_35_93_13_80 Sound attenuator infill unitsPrimary Pr_35_93_13_53 Mineral fibre infill units
CAWS	K40/10 Unit/ modular suspended ceilings K40/115 Unit/ modular suspended ceiling system K40/265 Infill units

Specification data - Sound attenuator infill units

Classification data
Standard	To EN 13964 (EN 717-1): Class E1.
Third-party certification	Cradle-to-cradle certified: Silver.
Form	Infill unit.
Rigidity	Rigid.
Application	Ceiling mounting.
Material	Stone wool.
Acoustic performance	-
Purpose	Absorber.
Sound absorption	Class A to BS EN ISO 11654.
Fire performance	-
Reaction to fire	A1.
VOC emissions	Very low.
Dimensions	-
Size (length x width)	600 x 600 mm. 1200 x 600 mm. 1800 x 600 mm. Guidance for specification option: A24, D, E24 and X edges.
Thickness (overall)	20 mm.
Profile	Linear.
Edges	A15. Guidance for specification option: MS / MS Easy Access: 50/ 100 mm. Weight: 2.3 kg/m². Recommended installation system: Rockfon® System T15 A. A24. Guidance for specification option: MS / MS Easy Access: 50/ 100 mm. Weight: 2.3 kg/m². Recommended installation system: Rockfon® System T24 A. D. Guidance for specification option: MS / MS Easy Access: 62/ 62 mm. Weight: 3.4 kg/m². Recommended installation system: Rockfon® System T24 Stepped Z D. E15. Guidance for specification option: MS / MS Easy Access: 60/ 100 mm. Weight: 2.8 kg/m². Recommended installation system: Rockfon® System T15 E. E24. Guidance for specification option: MS / MS Easy Access: 60/ 100 mm. Weight: 2.8 kg/m². Recommended installation system: Rockfon® System T24 E. X. Guidance for specification option: MS / MS Easy Access: 67/ 67 mm. Weight: 3.7 kg/m². Recommended installation system: Rockfon® System T24 X.
Surface pattern	Micro textured.
Finish	Visible side: micro-textured white painted fleece. Rear side: back fleece.
Colour	White.
Light reflectance	85%.
Humidity	Up to 100% RH. No visible deflection in high humidity C/0N
Cleanroom	ISO Class 5.
Impact resistance	Class 3A (Fastening clip). Impact resistance of Rockfon Sonar with edge Z or M mounted with fastening clip has been tested in accordance with EN13964 – Annex D and approved as Class 3A.
