Push-In Soffit Vent

Name: Push-In Soffit Vent
Brand: Timloc Building Products
SKU: c5ezuRvjGHfjakH2iDwVt6

Verified by manufacturer 3 days ago

1139 - Push-in soffit vent

Product certifications:

Efficient, circular ventilator in a range of colours.

Jump to:

Application

For roof eaves ventilation.
For remedial work on existing roofs.
On roofs where ventilation equivalent to a continuous 10 mm opening is required.
On roofs where the eaves incorporate a soffit board.

Efficient, circular ventilator in a range of colours.

Features and benefits:

Quality:

Color	Black Brown Grey White
Material	Polypropylene Guidance for specification option: Injection moulded.
Shape	Circle
Length	70 mm
Width	70 mm
Height	20 mm

Uniclass	Pr_30_59_94_78 Soffit grillesPrimary
CAWS	G20/900 Eaves soffit ventilators G20/97 Eaves soffit ventilators

SKU Code	1139

Classification data
Style	Circular, push-in.
Ventilation opening	2000 mm². Guidance for specification option: Should be spaced at 200 mm centres to achieve ventilation equivalent to a continuous 10 mm opening.
Colour	Grey.

Material	Polypropylene Guidance for specification option: Injection moulded.
Carbon dioxide equivalent
Carbon dioxide equivalent, as defined in BS EN 15804 Certified
Stage Normalized unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/kg) Stage:A1–A3 ('Production stage') Normalized unit :0.000 (kg CO₂ eq/kg) Declared unit :0.00032 Lower emissions
