Plain Roof Tile Vent Adapter

Name: Plain Roof Tile Vent Adapter
Brand: Timloc Building Products
SKU: pHktTQeujkqQqtRwwwAAco

Verified by manufacturer 1 month ago

Product certifications:

Provides Timloc Roof Tile Vents with a 110 mm duct or soil vent pipe connection.

Jump to:

Application

Roof ventilation applications.

Duct adapter for Timloc plain and interlocking plain inline roof tile vents.

Features and benefits:

Compatible with Timloc Plain Inline Roof Tile Vents Plain Roof Tile Vent / Interlocking Plain Roof Tile Vent / Low Profile Plain Tile Vent / SLIP Plain Roof Tile Vent without reducing the free vent area of the system.
Simply click into position to secure the adapter to base of the tile vent.
Provides a precise fit to 110 mm duct or Soil Vent Pipe.
Duct can be secured to the adapter with adjustable screw clamps, zip ties or glued/screwed.

Relevant standards:

Uniclass	Pr_30_59_96_92 Ventilation ductsPrimary
CAWS	U90/340 Through wall ventilator ducts F30/171 Ventilation ducts in external walling F30/17 Ventilation ducts in external walling

SKU Code	RVT-ADP

Classification data
Material	Injection-moulded polypropylene.
Accessories	Not required. Multi adapter. Guidance for specification option: RTV-ADMULTI. 110 mm flexi-pipe. Guidance for specification option: RTV-KIT1.
Diameter	110 mm.
Side profile	140 x 232 mm.
Weight	0.13 kg.
Standards	To BS 5250:2021, BS EN ISO 9001:2015, BS EN ISO 14001:2015.
Third-party certification	Complies with all relevant Building Regulations 2010, Satisfies all NHBC requirements.

Material	Polypropylene
Carbon dioxide equivalent
Carbon dioxide equivalent, as defined in BS EN 15804 Certified
Stage Normalized unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/kg) Stage:A1–A3 ('Production stage') Normalized unit :0.003 (kg CO₂ eq/kg) Declared unit :0.00322 Lower emissions
