PASSIVE PURPLE® EXTERNAL -Intelligent Facade Airtight Waterproof Membrane - Vapor Open - Vapor Control - ASTM A - Spray Applied Liquid Facade Membrane

Verified by manufacturer 2 months ago

Intelligent Membranes Canada Third party certifications:
  • KIWA BDA

    KIWA BDA

    Certificate type

Airtight liquid applied facade waterproof membrane. Water open but waterproof. 0.03 airtightness on the substrate its adhered to. Spray, roll or brush applied. Vapour Control membrane.

Jump to:
+1(613)9271011 Website

Application

Passive purple external is applied in 2 coats with an airless spray or paint roller which dries to form a flexible watertight membrane which is currently undergoing Passivhaus and Kiwa certification. The membrane forms a waterproof vapour open-faced membrane which can be used to reduce uncontrolled air filtration, the product also achieves a reaction to fire classification of B-s1, d0 to EN 13501- 1:2018.


Directions of use:

  • Remove salt efflorescence, dust, loose parts and standing water from the surface.
  • Apply on a closed surface; if necessary, fill holes and joints with a fast setting cement-based product or polyurethane foam.
  • Apply Passive Purple External at T < 5°C (also substrate temperature).
  • Application on humid surfaces is allowed, but remove standing water.
  • Do NOT add water or solvents.
  • Do NOT apply in full sunlight.
  • Do NOT apply during rain.
  • Apply Passive Purple External with an airless paint spray device, or paint roll, in two layers. Apply the second layer, after the first layer has dried.
  • Clean tools with water after use.
  • The product is ready to use.
  • Volatile organic content (VOC) free.


Description

Passive Purple External is a ready-to-use facade waterproof membrane based on specific pure acrylate polymer dispersions, that after application with an airless spray device or paint roll, it dries to a durable, flexible, watertight, UV-resistant and damp-open membrane.


Features and benefits:

  • Can adhere to any form of construction.
  • Cost Effective.
  • Passive Purple External is water-based and VOC-free.
  • Passive Purple External is applied to the external façade to make a super tough watertight vapour control membrane for weatherproofing and UV resistance.
  • Class A ASTM fire rated.
  • Passive Purple External lets in vapour where it’s needed while also ensuring your façade is airtight.

General information

Color

Manufacturer guidance

Other colours are available upon request. Consult manufacturer for details.

Finish

Other

Material

Polymer

Shape

Other

Formless

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

25 year

CMS

07 14 00 Fluid-Applied WaterproofingPrimary

07 27 26 F Fluid-Applied Membrane Air Barriers

02 56 19.13 Fluid-applied gas barrier

07 14 16 Cold Fluid-Applied Waterproofing
09 97 00 Special Coatings
09 96 00 High-Performance Coatings
09 90 00 Painting and Coating
09 54 00 Specialty Ceilings

09 05 61.13 Moisture Vapor Emission Control

07 87 00 Smoke Containment Barriers
07 80 00 Fire and Smoke Protection
07 77 00 Wall Specialties
07 70 00 Roof and Wall Specialties and Accessories
07 65 00 Flexible Flashing
07 25 00 Weather Barriers
07 20 00 Thermal Protection
07 10 00 Dampproofing and Waterproofing

07 01 00 Operation and Maintenance of Thermal and Moisture Protection

07 00 00 Thermal and Moisture Protection

07 27 00 Air Barriers
07 26 00 Vapor Retarders
07 11 00 Dampproofing
07 19 00 Water Repellents
09 91 00 Painting

32 00 00 Exterior Improvements

09 77 00 Special Wall Surfacing

07 26 00 Vapour Retarders

NMS

07 26 00 Vapour Retarders

NMS

07 26 00 Pare-vapeur

Product range

Methane & Radon Barrier
Weatherproofing
Facade Membrane - Retrofit Internal Air Barrier
Vapour Control - Air Barrier / External

Specification data - Fluid-Applied Waterproofing

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

Europe

Material

Polymer

Recyclability

Not recyclable due to its adhesion to other products

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0 %
