Unison Joints

High profile thermoplastic gasket dual seal expansion joint.

Jump to:
+61 07 3907 0500 Website

Application

Suitable for indoor and outdoor application and can be used with compatible finishes such as:

  • Tiles.
  • Epoxy.
  • Stone/Granite.
  • Terrazite.

Designed for hospital, food preparation areas, laboratories, cleaners rooms or wherever hygiene is imperative.

Can use anti-bacteria installation solution as an option during application.



Description

Also known as Morpho DT -the seal is purposely designed with smooth ripples to allow the seal to open, rather than stretch & break.  Some of its features include:

  • Architectural floor seal.
  • Santoprene primary seal.
  • Weather / Anti-pathogenic seal.
  • UV stable.
  • No bump transition.
  • Indoor and outdoor.
  • Multi-directional.
  • Indoor and outdoor.
  • Multi-directional.
  • Trolley safe.
  • Pathogenic.
  • Waterproof.

General information

Color

Beige

Black

Grey

Manufacturer guidance

Other colours are available by request, to check with the manufacturer.


Material

Thermoplastic

Length

4800 mm

Width

100 mm

150 mm

Height

49 mm

Warranty description

Two years.

Uniclass

Pr_35_90_53_53 Metal section movement jointsPrimary

NATSPEC National Classification System

0657 Resin Based Seamless Flooring

0651 Resilient Finishes

0632 Stone and Terrazzo Tiling

0631 Ceramic Tiling

SpecPack

09630 Stone Flooring and Wall Panels

09400 Terrazzo

09650 Resilient Flooring

09300 Ceramic Tiling

03360 Concrete Finishes

SpeedSpec

09650 Resilient Flooring

09300 Ceramic Tiling

03365 Concrete Finishes

Specification data - Metal section movement joints

Joint width (nominal)

128 mm.

Guidance for specification option:

Maximum exposed width for Mo50DT.

171 mm.

Guidance for specification option:

Maximum exposed width for Mo75DT.

Edging

-

Material

Thermoplastic.

Finish

Anodized.

Colour

Nature.

Insert

-

Colour

Black.

Grey.

Beige.

Length

4.8 m.

Material

Dual compound thermoplastic seal.

Seal colour

Black.

Grey.

Beige.

Manufacturer guidance

Other colour options are available by request.

Product code

Mo50DT.

Guidance for specification option:

Seal width at 50 mm x 2.

Mo75DT .

Guidance for specification option:

Seal width at 75 mm x 2.
