Thermally broken hinged door
Residential and commercial applications.
The Futureline Hinged Door system integrates seamlessly into the Futureline framing system to provide a high quality, thermally broken hinged door option. The 46mm door panel has been designed with clean, flat faces and a choice of standard or tall door rail options for added design flexibility. Midrails are also available to create a segmented look or to align with adjacent transoms. High quality hardware is featured throughout including thermally isolated hinges, heavy duty corner spigots and optional multi-point locks. The door panel profiles incorporate a pair of wide thermal spacers to minimise heat transfer while a selection of glazing bead options accommodate double glazing up to a width of 32mm.
The environmental credentials of the Futureline range extend beyond its excellent thermal design performance – the actual metal itself being formed from Ecometal™ incorporating up to 25% recycled metal content and sourced from smelters using hydro-electric energy sources.
Finish | Powder coated or anodised. |
Material | Aluminium. |
Shape | Manufacturer guidanceVarious profiles available. |
Size | Various sizes available. Max. Recommended Sizes Panel Height 2700mm Panel Width 1000mm. |
Uniclass | |
NATSPEC National Classification System | 0451a Windows and Glazed Doors – Metal 0451 Windows and Glazed Doors |
SpeedSpec | 08520 Metal Windows and Glazed Doors |
SpecPack | 08520 Metal Windows and Glazed Doors |
Standard | To AS 2047. |
Configuration | Various dimensions and configurations - see product literature |
Performance | |
Acoustic performance | |
Standard | To AS/NZS ISO 717.1. |
Door leaf | |
Glazing | |
Type | Double. |
Operation: | Manual. |
Configurations | Hinged. |
Door panels | Door Height 2.7m / Door Width 1.0m / Weight up to 115kgs. |
Frame dimensions | Stile: 46mm x 85mm / Rail: 46mm x 89mm / Rail: 46mm x 120mm. |
Performance: | Max SLS: 1500pa / ULS: 2500pa / WATER: 600pa. |
Standard | AS2047. |
Acoustics | Max Rw 36 (-2C;-2Ctr) |
Cyclonic impact testing | No |
Bushfire attack level (BAL) | BAL 29 DTS. |
Hardware | Door Closer / DDA Compliant Handle. |
Integral Accessories: | Stepped Threshold. |
Accessories: | Security Screen. Flyscreen. |
Country of material origin | Australia |
Country of product manufacture | Australia |
Recyclability | 100% recyclable. |
