EasyGate SPT outdoor
Verified by manufacturer over a year ago
Outdoor swing barrier speedgate. Designed to work in covered and non-covered applications.
Application
- Corporate offices.
- Government.
- Sports Stadia.
- Leisure clubs.
- Manufacturing plants.
- Distribution centres.
- Campuses.
- Schools.
Description
The Centurion EasyGate SPT - Outdoor is our state of the art swing barrier speedgate, upgraded to withstand the elements. The EasyGate is the perfect solution for all outdoor environments, using durable glass barriers combined with optical tailgate detection technology to provide a high throughput / high security gate.
The swing barrier design ensures the same narrow pedestal can be used for both standard and DDA lanes. The motorised, hand free barrier operation provides for a 'non contact' entry solution designed for outdoor use which provides a high level of security and ease of use.
General information
Warranty description | Three year |
Uniclass | |
NATSPEC National Classification System | 0451a Windows and Glazed Doors – Metal 0451 Windows and Glazed Doors |
SpecPack | 08200 Doors, Door Frames and Hatches |
Specification data - Glazed gates
Dimensions | |
Span | 920 mm (Max). |
Height | 1800 mm (Max). |
Depth | 1500 mm depth.Manufacturer guidancePedestal Depth. |
Posts | |
Material | Brushed stainless steel. |
Gate leaves | 10 mm tempered glass.Manufacturer guidanceSide infill panel: 6 mm Laminated glass. |
Accessible design | DDA compliant. Manufacturer guidanceDDA compliant when width meets appropriate standard. |
Type | Square profile (G) Round profile (R) |
Security | Tailgating / Cross over detection. |
Sensors | 36 pairs of IR sensors. |
Water resistance | IP 53 |
MeanTimeBetweenFailure | 5,000,000. |
Operation: | Normally closed. Manufacturer guidanceEmergency mode: Open automatically in the exit direction. |
Accessories: | Pressure sensing top USB convertor Ethernet convertor RF remote control EasyTouch TouchPanel T-MON SW Supercap (emergency power back-up) |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
Literature
Easygate SPT Outdoor- Brochure.
Easygate SPT outdoor datasheet.
