CeramaPANEL

Verified by manufacturer over a year ago

CeramaPANEL Classic

Fairview Architectural Variant:

Through-coloured, deemed non-combustible fibre cement façade panel in a range of finishes showcasing its natural, untreated texture.

Jump to:
+61 2 6352 2355 Website

Application

Suitable for a broad range of construction situations, offers design flexibility most favourable for New Build Community Projects (hospitals, aged care facilities, universities, schools, art galleries, government buildings).

Description

Through-coloured, deemed non-combustible fibre cement façade panel in a range of finishes showcasing its natural, untreated texture.


Features and benefits:

  • Colour impregnated throughout the panel.
  • Environmentally friendly.
  • Graffiti, scratch and impact resistant.
  • Deemed non-combustible.
  • Available in large sheets, the panels while thin have outstanding physical properties.
  • Uses a proven rain-screen system that allows building to ‘breathe’ naturally along with providing excellent insulation.
  • Can be perforated and embossed.
  • Allows the achievement of flawless, intricate details.
  • Life expectancy exceeding 50 years, even in demanding exterior applications.
  • 15 years warranty.

General information

Finish

-

Manufacturer guidance

Refer to Variants.

Material

Fibre cement facade boards.

Shape

Rectangle

Length

2500 mm

3050 mm

Width

1250 mm

Warranty description

15 years.

Uniclass

Ss_25_20_72_72 Rigid sheet cladding systemsPrimary

SpeedSpec

07462 Cladding External Walls

NATSPEC National Classification System

0438 Cladding – Cement Board

0434 Cladding - Flat Sheets and Panels

SpecPack

06165 Fibre Cement Products

07415 Steel-Faced Autoclaved Aerated Concrete (AAC) Panels

Specification data - Rigid sheet cladding systems

System performance

Material and product performance

Breather membrane

-

Material

-

Manufacturer guidance

Ventilated Facade systems also known as double-skin facades or rain-screens, assist in protecting buildings against wind, rain and temperature variations and keeping the building dry and energy efficient.

Cladding panels

Fibre-reinforced cement boards

System accessories

20 x 35 Facade Top Hat, 50 x 35 Intermediate Top Hat, 8.0 mm Back Flashing, 3.5mm Back Flashing, Tape, Screws, Cutting Blades and Drill Bits.

Length

2500 mm.

3050 mm.

Manufacturer guidance

Each sheet can be easily cut onsite, shortens lead times and hastening the completion date for many new build projects.

Width

1250 mm.

Thickness

9 mm.

Cladding profiles

Fixing system

Panel

Batten

Sarking

Accessories

Colours

CPC-1014

CPC-1018

CPC-2008

CPC-3020

CPC-4002

Show more

Profile

Classic

Depth

Groove

Hewn

Infuse

Show more

Manufacturer guidance

Refer to Variants.
