Summary
A range of glue-laminated Timber Systems including hardwood or softwood beams, columns, floors and roof structures.
Third party certification
QA Certificate
Warringtonfire Aus Pty Ltd: Certificate of Assessment - Effective char depth of Victorian Ash Glulam timber beams and columns
QA Certificate
Warringtonfire Aus Pty Ltd: Certificate of Assessment - Effective char depth of Victorian Ash Glulam timber beams and columns
Shape
Rectangular.
-
-
Finish
Coarse.
-
-
Material
Glue-Laminated Hardwood.
-
-
Specification
Timber
-
-
-
Wood species and origin
Victorian Ash.
-
-
Adhesive grade
Externally rated, high temperature PUR.
-
-
Additional properties
Product Reference
MASSLAM 50
-
-
Factory finish
Coarse.
-
-
Stress grade
GL 21/45.
-
-
BendingStrength
50 MPa.
-
-
Tension strength
Parallel/ Perpendicular: 25 / 0.8 MPa.
-
-
ShearStrength
5.0 MPa.
-
-
Compression strength
50 MPa.
-
-
BearingStrength
Parallel/ Perpendicular: 67 / 23 MPa.
-
-
Modulus of elasticity
21,000 MPa.
-
-
Modulus of rigidity
1,400 MPa.
-
-
Joint group
JD2.
-
-
Design density
850 kg/m³.
-
-
Formaldehyde emissions
None (E-0).
-
-
Certification
PEFC.
-
-
Char rate
0.4523 mm per minute.
-
-
Species
Mountain Grey Gum.
-
-
Colour:
blonde.
-
-
Sustainability data
Contains Red List materials
No
-
-
Country of material origin
Australia
-
-
Embodied carbon
MASSLAM 45 673kg per m³.
-
-
Recyclability
Yes.
-
-
