Robust secret fix soffit
Warringtonfire
Certificate type
Range of aluminium soffits including secret fix, top hat, and standard profiles. All options are virtually maintenance-free over the life of the building.
Soffits for a wide range of applications. TrimFix Soffit.
Range of aluminium soffits including secret fix, top hat and standard profiles. All options are virtually maintenance-free over the life of the building.
Secret fix/ robust secret fix/ top hat soffits:
Extruded soffits:
Slimline is a secret fixing interlocking extruded plank with 'V' channel groove at 50 mm centres. Ideal for deep overhangs where flatness with panel-type products may be difficult to achieve.
The top hat is a simple brake-pressed profile which can be manufactured in such a wide variety of widths and gauges it is suitable for almost any application. The recessed joints along the two long edges provide a shadow rebate within which fixings can be hidden. This product can also be provided with discreetly located airflow fine-line ventilation slots to allow sufficient ventilation of the void whilst preventing vermin ingress.
Color | Silver Other Beige Black Blue |
Finish | Powder-coated Anodized Textured Metallic Other |
Material | Aluminium |
Shape | Other |
Length | 3000 mm Guidance for specification option: Maximum length per unit. Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Other Manufacturer guidanceFinish warranty available and determined upon applicated based upon geographical location. |
Uniclass | Pr_65_50_35_02 Aluminium combined fascias, soffits and gutters |
CAWS | R10/13 Combined fascia, soffit and gutter R10/321 Combined fascia, soffit and gutter G20/99 Fascias/ barges/ soffits G20/950 Fascias/ barges/ soffits |
Material | Aluminium long strip. |
Item | Soffit. |
Form of delivery | Preformed item.Guidance for specification option: Extruded. |
Size | |
Thickness (minimum) | Guidance for specification option: Consult manufacturer for options and insert requirements. |
Width | Guidance for specification option: Consult manufacturer for options and insert requirements. |
Fixing | Secret fix. |
Finish | Polyester powder-coated to BS 6496.Guidance for specification option: Standard; insert colour requirements below. Anodized.Guidance for specification option: Insert colour requirements below. Heritage textured.Guidance for specification option: Insert colour requirements below. Metallic.Guidance for specification option: Insert colour requirements below. Special.Guidance for specification option: Insert colour requirements below. |
Colour | RAL, colour.Guidance for specification option: Insert requirements (polyester powder coating only). BS 4800, colour.Guidance for specification option: Insert requirements (polyester powder coating only). Syntha Pulvin, colour.Guidance for specification option: Insert requirements (polyester powder coating only). Other.Guidance for specification option: Insert requirements (all finishes). |
Texture | As Finish. |
Profile | Secret fix. |
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 16 kg CO₂ eq/kg Self declared |
Recyclability | Potential 95% + recyclability |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 95 % |
