With its wide range of colour options, the Kingspan Day-Lite Klick provides a stylish wall lighting solution.
Designed for standalone use where no integration with insulated panels is required and can also be combined with an extruded aluminium frame to allow for integration with a range of building materials including insulated panels, brick and render.
With its wide range of colour options, the Kingspan Day-Lite Klick provides a stylish wall lighting solution. The polycarbonate panels feature an innovative ‘clicked’ jointing detail, allowing them to be quickly installed either as a full height system or integrated within other building materials.
Features and benefits:
Quality and Durability:
Kingspan insulated panels are manufactured from the highest quality materials, using state of the art production equipment to rigorous quality control standards, complying with:
Color | Clear White Guidance for specification option: Opal. Blue Green Purple |
Material | Polycarbonate Aluminium |
Shape | Rectangle |
Length | 12000 mm |
Width | 500 mm |
Warranty description | Guidance for specification option: Product warranty. |
Uniclass | |
CAWS | H43/160 Profiled plastics sheet H43/30 Profiled plastics sheet |
Product range |
Performance requirements | |
Reaction to fire | B-s1,d0 in accordance with BS EN 13501-1:2007. |
Light transmission | 60%. |
Fragility | Manufacturer's standard. |
Impact resistance | Manufacturer's standard. |
Thickness (nominal) | 40 mm. |
Profile | Manufacturer's standard. |
Length | 12 000 mm. |
Cover width | 500 mm. |
Finish as delivered | Manufacturer's standard. |
Colour | Clear. |
Thermal conductivity | 0.98 W/m²K. |
Product Reference | KS500 DLKK Guidance for specification option: Weight: 4.0 kg/m². A full system weight, including perimeter extrusions, will depend on project-specific design. Contact manufacturer's Technical Services Department for more information. |
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
