Anti-Skate Blade

Verified by manufacturer 5 months ago

Anti-Skate Blade Standard (102-101)

Studmarc Variant:

Anti-Skate Blade.

Jump to:
BOS
+44(0)1686 807 450 Website

Application

These blades can be installed in:

  • Brickwork.
  • Coping.

Description

This anti-skate blade is manufactured from 1.4404 (316L) stainless steel and has a matte finish. They’re designed to be inserted into mortar joints between coping, or bricks. There are two variants, one for retrofit and one for use at the time a wall is erected.

They make a suitable skate deterrent as they block off straight lines’ that skaters may look to grind on and keep the furniture or walls in their original condition.

Blade protrusion: 5 mm, thickness: 4 mm.



The blade is designed to protrude slightly from the top and side of brickwork and coping, making its presence seamless, blending into the surrounding brickwork

while making it clear that the surface is not for skating on. The protrusion is subtle enough that anyone passing by won't get caught on the blade and its rounded edges mean that anyone that comes into contact with it won't come to

any harm.

The added benefit of the blade being installed in the wall is that it has unmatched strength and is highly resistant to vandalism.


Alternate sizing is available with the bespoke product service.


Bespoke sizing guide:

Inner radius: 4–60 mm.


Finishing options:

  • Bright polish.
  • Sandblasted.


Available material options:

Brass.


Features and benefits:

  • Retrofittable option available.
  • Installed in coping or brickwork.
  • Installed using a 12” angle grinder and epoxy resin.
  • The anti-skate blade can be manufactured to any radius.

General information

Color

Silver

Finish

Matt

Sandblasted

Polished

Material

Stainless steel

Brass

Aluminium

Length

100 mm

Bespoke

Width

4 mm

Bespoke

Height

45 mm

60 mm

Bespoke

Warranty description

Lifetime

Uniclass

Pr_35_90_60_77 Skateboard deterrent devicesPrimary

Specification data - Skateboard deterrent devices

Material

Brass.

Stainless steel (1.4404/ 316L).

Profile

Blade.

Size

60 x 100 mm.

Bespoke.

Guidance for specification option:

Bespoke sizes also available:

  • Radius: 4–100 mm.
  • Height: 45–200 mm.
  • Width: 4–10 mm.

Installation

Installed at time of wall/ brick/ coping installation.

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

United Kingdom

Recyclability

Should the need to recycle the Anti-Skate blades arise, all material options can be melted down and reused again.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1

Literature

Anti-Skate Blade - Datasheet

Anti-Skate Blade - Datasheet

Anti- Skate Blade Retro Fit - Datasheet

Anti- Skate Blade Retro Fit - Datasheet
